Description：
The PION® PMA- serie Precision pressure gauge is a precise instrument acclaimed for dependability, safety and performance. high-quality test gauge has been specifically designed for the measurement of pressures with high accuracy. With its accuracy class of 0.25 the Bourdon tube pressure gauge is suitable for testing industrial type pressure gauges or for precision measurement in laboratories.Optionally, an accuracy class of 0.25 is available for pressures ≤ 400 bar.For the respective measuring requirement, a scale range between 0 ... 0.6 and 0 ... 1000 bar can be selected.The optimal readability of the instrument, with a nominal size of 150 mm(6"), is achieved via a knife edge pointer and a dial with fine divisions. Supported through the optional mirror band scale, the parallax error can be eliminated. For harsh operating conditions (e.g. vibrations), the instruments arealso available with an optional liquid filling type. For this instrument, an optional CNS calibration certificate can be generated. Safe storage and transport is ensured by a transport case(accessory).
Key Features:
• adjustment eases span calibration
• Mirror-band dial and knife-edge pointer eliminates paralax error
• Solid-front case design for safety
• Wear-resistant precision movement core
• Case designed for easy panel mounting
Applications:
■ Industrial Market:
■ Test Calibration of general pressure gauges
■ Specialized OEM Equipment
■ Medical and Life Sciences:
■ Test Measurement & Validation
■ Calibration Labs
■ Precision measurement in laboratories
■ High-accuracy pressure measurement
■ Testing of industrial type pressure gauges
The PION® PMA- serie Precision pressure gauge is a precise instrument acclaimed for dependability, safety and performance. high-quality test gauge has been specifically designed for the measurement of pressures with high accuracy. With its accuracy class of 0.25 the Bourdon tube pressure gauge is suitable for testing industrial type pressure gauges or for precision measurement in laboratories.Optionally, an accuracy class of 0.25 is available for pressures ≤ 400 bar.For the respective measuring requirement, a scale range between 0 ... 0.6 and 0 ... 1000 bar can be selected.The optimal readability of the instrument, with a nominal size of 150 mm(6"), is achieved via a knife edge pointer and a dial with fine divisions. Supported through the optional mirror band scale, the parallax error can be eliminated. For harsh operating conditions (e.g. vibrations), the instruments arealso available with an optional liquid filling type. For this instrument, an optional CNS calibration certificate can be generated. Safe storage and transport is ensured by a transport case(accessory).
Key Features:
• adjustment eases span calibration
• Mirror-band dial and knife-edge pointer eliminates paralax error
• Solid-front case design for safety
• Wear-resistant precision movement core
• Case designed for easy panel mounting
Applications:
■ Industrial Market:
■ Test Calibration of general pressure gauges
■ Specialized OEM Equipment
■ Medical and Life Sciences:
■ Test Measurement & Validation
■ Calibration Labs
■ Precision measurement in laboratories
■ High-accuracy pressure measurement
■ Testing of industrial type pressure gauges
