2.6Inch Pressure gauges with capsule elements
Product Model:PMB26-AEC-B050K-BP14
Product Brand:PIONEER
Product Type:Mechanical pressure gauges
Product Series:Pressure gauges with capsule elements series
Meter Diameter:2.6Inch(66mm)
Pressure range:0~5kPa/0~500mmAq
Scale unit:kPa(black)/mmAq(Red)
Structural styles:Arc surface Polycarbonate window embedded structure
Case Material:SUS304 Stainless steel
Cover ring material:Without
Transmission components Material: copper alloy
Elastic element material: copper alloy (capsule)
Connector Material: copper alloy (Plating nickel)
Meter Window Material: Arc surface Polycarbonate window
Dial Material: Aluminum (white background)Front adjust zeroing
Pointer Material: Aluminum
Mounting Type:Radial mounting
Form of pressure:Pressure(relative pressure)
Connection Screw Thread:PT1/4(ZG1/4)
Accuracy class: 2.5%f.s.
