2.5 Inch Axial all stainless steel case vacuum gauges with capsule elements
Product Model:PMB26-BFM-V502P-BP14
Product Brand:PIONEER
Product Type:Mechanical pressure gauges
Product Series:Pressure gauges with capsule elements series
Meter Diameter:2.5Inch(65mm)
Pressure range:0~-5000Pa/0~-500mmAq
Scale unit:Pa(black)/mmAq(Red)
Structural styles:Case and Cover-ring wild card tighten the structure
Case Material:SUS304 Stainless steel
Cover ring material:SUS304 Stainless steel
Transmission components Material:SUS304 Stainless steel
Elastic element material: SUS316Stainless steel (capsule)
Connector Material: SUS316 Stainless steel
Meter Window Material: Safety glass window
Dial Material: Aluminum (white background)Front adjust zeroing
Pointer Material: Aluminum
Mounting Type:Axial center mounting
Form of pressure:Vacuum (relative pressure)
Connection Screw Thread:PT1/4(ZG1/4)
Accuracy class: 2.5%f.s.
